RX62T Motor & Inverter Control

The Renesas RX62T Group of high-performance microcontrollers with a maximum operating frequency of 100MHz are designed for motor control. They are equipped with multifunction timers (MTU, GPT), high-speed 12-bit A/D converter, and 10-bit A/D converter for facilitating motor control. The products also incorporate many safety features to comply with the IEC60730 safety standard for home appliances. In addition to a maximum of 256KB flash and 16KB RAM on-chip memory, they have a maximum of 32KB of on-chip flash memory for data storage. 64-pin to 112-pin packages are available.

RX62T Overview

RX62T Motor Control Image

High-performance CPU and FPU capability, and advanced analog and timer peripherals, make the RX62T an ideal solution for inverter and motor control applications. Renesas can help you develop your motor control solution with kits and firmware that support many kinds of motor control, including ultra-quiet, energy- efficient, and high-precision three-phase sensorless vector control.

In the home appliance example shown here, the RX62T is driving two three-phase motors simultaneously using its advanced PWM timers. These timers are well suited for Brushless DC three-phase motors by having complimentary PWM outputs with automatic dead-time insertion, an emergency "Shut-down" (stop) input, and quadrature encoder inputs for speed and direction feedback.

The RX62T's advanced analog subsystem with multiple sample-hold circuits enables sampling of three simultaneous current measurements. It also offers programmable operational amplifiers and integrated window comparators to eliminate external components. The 12-bit ADCs have a fast 1μsec conversion time, can be triggered by the PWM timers, and provide self-diagnostic capability.

RX62T MCUs provide improved motor/inverter control timers and enhanced analog peripherals for implementing very precise motor control and positioning applications. The MTU3 and GPT timer peripherals enable one MCU to control three motors simultaneously. An FPU and improved analog functions make these MCUs ideal for use with three-shunt or single-shunt vector-type motor control methods.

CPU core Execution Unit:
  • Integer operations, 5-stage execution pipeline
  • 32-bit single precision Floating Point Unit compliant to IEEE-754 specification
Digital Signal Processing:
  • •48-bit MAC, 80-bit RMPA, 32-bit Barrel Shifter
Register Set:
  • 9 X 32-bit Control Registers
  • 16 X 32-bit General Purpose Registers
  • 48-bit Accumulator Register
Memory Protection Unit:
  • Eight programmable protection regions
Interrupt Control Unit:
  • Configurable for Normal and Fast interrupt handling with option to dedicate up to four General Purpose registers for interrupt use
On-chip Debug:
  • JTAG or 2-wire
  • High-speed trace (6-wire)
Maximum operating frequency 100MHz (80MHz for 64-pin LQFP 5V version)
Power supply voltage Choose devices 2.7 to 3.6V or 4.0 to 5.5V
Zero-wait Flash Up to 256KB
Data Flash Up to 8KB
SRAM Up to 16KB
On-chip peripheral functions Communication:
  • CAN 1unit (Optional)
  • 1 LIN, 1 I2C, 3 SCI, 1 SPI
Timers:
  • MTU3 16-bit x 8 channels
  • General purpose PWM timer 16-bit x 4 channels
  • Compare Match Timer 16-bit x 4 channels
Data Movement:
  • 85 DTC channels, linked-list control
Analog:
  • 8 channels 12-bit ADC, 1 us conversion time
  • 12 channels 10-bit ADC, dual sample-hold, 1 us
  • 6 Programmable Op Amps and 6 Comparators
Packages LQFP64, LQFP80, LQFP100, LQFP112

RX610 Microcontrollers

Part Number Program
Memory (KB)		 Data
Flash (KB)		 RAM
(KB)		 Pins Connectivity Datasheets App
Notes		 Buy Now
R5F562TABDFF#V0 256 32 16 57 CAN View View Buy Now
R5F562T6EDFM#V0 64 32 8 46 - View View Buy Now
R5F562TAEDFM#V0 256 32 16 46 - View View Buy Now
R5F562TABDFM#V0 256 32 16 46 CAN View View Buy Now
R5F562TADDFM#V0 256 32 16 46 - View View Buy Now
R5F562T7DDFP#V0 128 32 8 76 - View View Buy Now
R5F562TAADFM#V0 256 32 16 46 CAN View View Buy Now
R5F562TAADFF#V0 256 32 16 57 CAN View View Buy Now
R5F562TABDFP#V0 256 32 16 76 CAN View View Buy Now
R5F562TADDFP#V0 256 32 16 76 - View View Buy Now
R5F562TABDFH#V0 256 32 16 82 CAN View View Buy Now
R5F562TAADFP#V0 256 32 16 76 CAN View View Buy Now
R5F562TAADFH#V0 256 32 16 82 CAN View View Buy Now
R5F562T6BDFM#V0 64 32 8 46 CAN View View Buy Now
R5F562T6DDFM#V0 64 32 8 46 - View View Buy Now
R5F562T7EDFM#V0 128 32 8 46 - View View Buy Now
R5F562T6ADFM#V0 64 32 8 46 CAN View View Buy Now
R5F562T6DDFF#V0 64 32 8 57 - View View Buy Now
R5F562T7DDFM#V0 128 32 8 46 - View View Buy Now
R5F562T7DDFF#V0 128 32 8 57 - View View Buy Now
R5F562T7EDFP#V0 128 32 8 46 - View View Buy Now
R5F562T7BDFP#V0 128 32 8 76 CAN View View Buy Now
R5F562T7ADFP#V0 128 32 8 76 CAN View View Buy Now

RX610 Development Kits

Part Number Series Description Buy Now
R0K5562T0S000BE Renesas Starter Kits (RSK) KIT STARTER FOR RX62T Buy Now
